Meets the development needs of mining projects, compatible with diverse scenarios including excavation, loading, and ore transportation
Battery capacity options range from 400 to 600 kWh, compatible with batteries from various manufacturers
Standardized base plate adapts to multiple vehicle models for excavation, loading, and ore transportation.
Optional locking mechanisms include pneumatic drive, hydraulic drive, pin-lock, and downward pressure
Integrated charging and swapping design compatible with international battery swapping solutions
Compatible with fire suppression systems
|
Name |
YX400 |
YX600 |
|
Rated Capacity (kWh) |
400.6 |
400.6 |
|
Rated Voltage (V) |
618.2 |
618.2 |
|
Rated Charging Capacity |
Single-plug: 300A ~ 600A / Dual-plug: 600A ~ 1200A |
Single-plug: 300A ~ 600A / Dual-plug: 600A ~ 1200A |
|
Battery Brand |
CATL |
CATL |
|
Thermal Management Approach |
Liquid-cooled and heated |
Liquid-cooled and heated |
|
Overall Dimensions(L*W*H) |
2460*845*1720mm |
2460*845*2230mm |
|
Protection Rating |
IP67 |
IP67 |
|
Upper Frame System Weight (t) |
3.6 |
5.2 |
|
Weight of vehicle-mounted base support system (t) |
0.5 |
0.5 |
