Customized solution
Easy to assemble
Multiple options
Convenient transportation
Skid mounted design
Support fork and lift transportation
Flexible deployment, diverse combinations
Meet the actual scenario needs of customers
No foundation pit, low civil engineering requirements
The fastest stop in one day
Fearless of extreme cold, high temperatures, high seas, and sandstorms
Various extreme scenarios such as high humidity, high salt spray, etc
|
Battery Swap Time |
≤4.5min |
|
|
Standard Battery |
282 / 350 / 400 / 600kWh |
|
|
Design Number of Charging Stations |
7 work stations + 1 transfer station |
9 work stations + 1 transfer station |
|
Service Capability |
168 train trips per day* |
216 train trips per day* |
|
Charging Cabinet Power Rating |
8 /10*320 / 400kW (Power rating can be adjusted based on actual requirements) |
|
|
Charging Current |
600A |
|
|
Distribution Capacity |
2000 ~ 3150 kVA (depending on charging configuration) |
|
|
Operating Temperature Range |
-20°C ~ 55°C (Arctic Edition: -40°C ~ 55°C) |
|
|
Operating Humidity Range |
5%-95%RH |
|
|
Use Altitude |
≤2000m（High-altitude Version ≤4000m） |
|
|
Wind Resistance Rating |
≤ Level 14 |
|
|
Seismic Resistance Grade |
Seismic design intensity ≤ 7 degrees，≤0.15g |
|
|
Whole-Site Protection |
New dust-proof door, Temperature control system, LED display, Voice prompts |
|
|
Standard Edition Dimensions (L*W*H) |
17.0*4.2*5.3m |
|
*Based on a charging time of 60 minutes
