Greater capacity, lighter weight, smaller size, lower center of gravity
Pack system isolated from water-cooled unit for dust-free operation
Integrated charging and swapping design compatible with international battery swap solutions
Battery capacity options range from 282 to 600 kWh, compatible with batteries from various manufacturers
Standardized modular products eliminate the need for secondary tuning by vehicle manufacturers
Onboard base tray with mechanical manual locking mechanism for simple operation; low weight of 290kg base tray; reduced cost by replacing four connectors with one
|
Name |
CSP400 |
CSP600 |
|
Rated Capacity (kWh) |
400.6 |
600.9 |
|
Rated Voltage (V) |
618.2 |
618.2 |
|
Rated Charge/Discharge Capacity (A) |
600 / 600 |
600 / 600 |
|
Battery Brand |
CATL |
CATL |
|
Battery Model |
D06 |
D06 |
|
Thermal Management Approach |
Liquid-cooled and heated |
Liquid-cooled and heated |
|
Overall Dimensions(L*W*H) |
2490*840*1660mm |
2490*840*2230mm |
|
Protection Rating |
IP67 |
IP67 |
|
Upper Frame System Weight (t) |
3.3 |
4.8 |
|
Weight of vehicle-mounted base support system (t) |
0.3 |
0.3 |
