Direct reduction architecture reduces power loss and leads the industry in efficiency

The EPDD high-efficiency overcharging system uses 10kV high-voltage direct drop technology to improve station efficiency (including transformers) by at least 4 percentage points compared to traditional solutions, significantly reducing daily operational power losses. Taking the 2400kW system (2 * 1200kW) as an example, a single battery swapping station can save over 200000 yuan in electricity bills annually (calculated based on an average of 10 hours of daily operation).

High protection design suitable for complex environments

Adopting an independent air duct and heat exchanger heat dissipation design, the overall protection level of the machine reaches IP65, effectively isolating high pollution factors such as dust, moisture, salt spray, etc., suitable for harsh scenarios such as ports, mines, and power plants.

At the same time, this design greatly extends maintenance intervals and improves operational efficiency; The switch components are few, the control is simple and reliable, the equipment failure rate is reduced, the quality and efficiency of the entire life cycle are improved, and the equipment life is extended to more than 10 years.

Efficient charging module, achieving ultra-high power output

The charging module adopts a new three-level+10kV direct drop control technology, with a maximum conversion efficiency of 98.5%; Simultaneously adopting intelligent temperature control technology can achieve adaptive speed regulation of the fan, realizing energy saving and noise reduction in the system.

The charging module has a wide DC output range of 200~1000VDC, achieving isolated DC output; Support parallel expansion of multiple modules; There are no high-order harmonics in the grid side current, and the THD of the current is ≤ 3%.

Ultra fast integration, compatible with multiple terminals, supported by all models

Flexible configuration of host power cabinet:

1-channel liquid cooled supercharging interface (600A/1000V, compatible with 800V high-voltage platform models).

7-way fast charging interface (250A/1000V, compatible with passenger cars, commercial vehicles, construction machinery, etc.).

Covering various charging scenarios such as passenger cars, heavy-duty trucks, mining trucks, and ships, the single system meets the mixed needs of "overcharging+fast charging".
